IMSG171P-50S
Home / Semiconductor / IMSG171P-50S
IMSG171P-50S
> 5.500 pcs in our german Stock
| HIGH PERFORMANCE CMOS COLOUR LOOK-UP TABLE IC |
|---|
| 50MHz | Vcc 7V |
| Manufacturer: STMicroelectronics |
| Package: DIP28 |
| Designed to be compatible with IBM PS/2, VGA graphics systems. |
|---|
| The device is pincompatible to IMSG176 and compatible to other producers like GM171 , OTI-066 and TR9C1710 |
Request Quote
Please complete all required fields with your contact information. Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us: request@pargos.de
Technical information
- 256K possible colours.
- Single monolithic, high performance CMOS.
- Pixel word mask.
- RGB analogue output, 6 bit DAC per gun, composite blank.
- Low DAC glitch energy.
- Video signal output into 37.5Ohm.
- Up to 8 bits per pixel.
- TTL compatible inputs.
- Microprocessor compatible interface.
- Single +5V +/- 10% power supply.
- Low power dissipation. 880mW max. at maximum pixel rate.
- Standard 600 mil 28 pin DIL .
- Pin compatible with IMS G176
NOT PULLED - NOT USED - NOT REFURBISHED - NOT SOLDERED - NOT RE-MARKED - NOT FAKED
EXCLUSIVELY NEW OLD STOCK (NOS)
