IMSG176P-80SF

> 5.500 pcs in our german Stock

HIGH PERFORMANCE CMOS COLOUR LOOK-UP TABLE IC
80MHz | Vcc 7V
Manufacturer: STMicroelectronics
Package: DIP28
Designed to be compatible with IBM PS/2, VGA graphics systems.
The device is pincompatible to IMSG171 and compatible to other producers like GM176 , OTI-066 and TR9C1710
BUW1215

Request Quote

Please complete all required fields with your contact information. Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us: request@pargos.de

Contact us


Technical information

  • Compatible with the RS170 video standard.
  • Pixel rates up to 80MHz.
  • 256K possible colours.Single monolithic, high performance CMOS.
  • Pixel word mask.
  • RGB analogue output, 6 bit DAC per gun, composite blank.
  • Low DAC glitch energy.
  • Video signal output into 37.5Ohm.
  • Up to 8 bits per pixel.
  • TTL compatible inputs.
  • Microprocessor compatible interface.
  • Single +5V +/- 10% power supply.
  • Low power dissipation. 950mW max. at maximum pixel rate.
  • Standard 600 mil 28 pin DIL .
  • Pin compatible with IMS G171


NOT PULLED - NOT USED - NOT REFURBISHED - NOT SOLDERED - NOT RE-MARKED - NOT FAKED

EXCLUSIVELY NEW OLD STOCK (NOS)
