LF25CDT
> 50.000 pcs in our german Stock
| VERY LOW DROP VOLTAGE REGULATOR |
|---|
| WITH INHIBIT | 2.5V | Vcc 16V |
| Manufacturer: STMicroelectronics |
| Package: DPAK |
| Pincompatible with other manufactures (ON,TI, NSC etc.) in DPAK |
|---|
| The very Low Drop voltage (0.45V) and the very low quiescent current make them particularly suitable for Low Noise, Low Power applications and specially in battery powered systems. |
Request Quote
Please complete all required fields with your contact information. Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us: request@pargos.de
Technical information
The LF00 series are very Low Drop regulators available in PENTAWATT, TO-220, TO-220FP,DPAK and PPAK package and in a wide range of output voltages.The very Low Drop voltage (0.45V) and the very low quiescent current make them particularly suitable for Low Noise, Low Power applications and specially in battery powered systems.
- VERY LOW DROPOUT VOLTAGE (0.45V)
- VERY LOW QUIESCENT CURRENT (TYP.50 μA IN OFF MODE, 500 μA IN ON MODE)
- OUTPUT CURRENT UP TO 500 mA
- LOGIC-CONTROLLED ELECTRONIC SHUTDOWN
- INTERNAL CURRENT AND THERMAL LIMIT
- ONLY 2.2 μF FOR STABILITY
- AVAILABLE IN ± 1% (AB) OR ± 2% (C) SELECTION AT 25 °C
- SUPPLY VOLTAGE REJECTION: 80db (TYP.)
- TEMPERATURE RANGE: -40 TO 125 °C
NOT PULLED - NOT USED - NOT REFURBISHED - NOT SOLDERED - NOT RE-MARKED - NOT FAKED
EXCLUSIVELY NEW OLD STOCK (NOS)
